The drone was designed to contribute useful data to civil/military usage by transmitting atmospheric environment information (wind direction, wind speed,
temperature, fine dust, Sox, Nox, etc.) in real time high-altitude vertical meteorological observation.
- The drone will observe and remit the wind direction and wind speed data required by artillery and CBR(Chemical, Biological, Radiological) units
- The drone will contribute to reconnaissance operation by acquiring local weather information during the operation of unmanned aerial vehicles (UAV) of the Air Force
- The drone will transmit and acquire real-time data necessary for proximity monitoring and proliferation simulation in case of disasters
Specification
· Size : 470 x 470 x 870mm
· Weight : 2.73kg/4.13kg(w/battery)
· Battery : 22.2v/10,000mah
· Max Flight Time : 32min
· Max Speed : 54km/h
· Payload : 0.3kg
· Operation Range : 3km
· Max Flight Altitude : 1km
· Wind Resistance : 18m/s
· Water Resistance : IPx4 and above
Special Features
· Realtime Environmental Monitoring and 3D Mapping of Environmental Data
· Double Quad Airframe with 8 Propellers
· Thermal Insulation Housing Fuselage(Operation at -20℃~40℃)
· Flight in Rain(IPx4) and Strong Wind Resistance(18m/s Max)
· Autonomous Flight Control and Safe RTB
· Realtime FHD Transmission
· AI 3D Mapping Technology for Safe Skyway
Mission Equipment
· 10 x Zoom Camera
· Weather Sensor(Temperature, Humidity)
· Wind Direction and Speed Sensor
· Particulate Material Sensor
· Sox, Nox Sensor
Field of Application
· Military Operations
· Offshore Survey & Inspection
· Weather Forecast
